Industrial Application & Brand Cooperation
NXB Series Circuit Breaker: Highly responsive, perfect for motor applications, and enhanced safety features. AC Contactor: Equipped with silver contacts to carry more current, ensuring a longer service life. JSZ3 Series Time Relay: Acts as a motor protector by disconnecting power when abnormalities like open phase, overload, or three-phase imbalance occur, effectively safeguarding the motor. Fuse: Integrated into the circuit to automatically cut off power during short-circuits or overloads, ensuring circuit safety.
| product name | star delta panel for pump /fan /motor | box/cabinet size | 400*300*200mm |
| product type | One control by one | box/cabinet thickness | 0.8-1.5mm |
| power | 2.2kw--55kw | Instal type | wall mounting |
| voltage | AC380V | weight | 5.8kg |
| funtion | Start Stop | Warranty | one year |
| Feature | Overload protection | Phase protection | Short circuit protection |
| power model | A(mm) | B(mm) | C(mm) |
| 11-18.5kw | 400 | 300 | 180 |
| 22-30kw | 500 | 400 | 200 |
| 37-45kw | 600 | 400 | 200 |
| Power(KW) | | 380V Contactor | Fuse |
| 15KW | 63A | CJX2-2510(two pcs) CJX2-1801(one pcs) | 2-20A |
| 18.5KW | 63A | CJX2-3210(two pcs) CJX2-2501(one pcs) | 20-80A |
| 22KW | 100A | CJX2-4011(two pcs) CJX2-3201(one pcs) | 20-80A |
| 30KW | 100A | CJX2-5011(two pcs) CJX2-4011(one pcs) | 20-80A |
| 37KW | 160A | CJX2-6511(two pcs) CJX2-5011(one pcs) | 20-80A |
| 45KW | 160A | CJX2-9511(two pcs) CJX2-6511(one pcs) | 20-80A |
Certifications
Installation Instructions
Wiring Diagram: Connect the upper power supply to the line and the lower part to the motor.
Professional Technical Team: Offering comprehensive one-stop service and remote technical support.
Secure Payments: Every transaction on is protected with stringent SSL encryption and PCI DSS data protocols. Easy Return & Refund: Claim refunds for missing or defective orders, with free local returns for qualifying purchases. ensures the safety of all orders placed and paid on the platform.
